aurelian_bln

Modul comfort defect

Recommended Posts

aurelian_bln

Va salut. Am deschis topic nou ca nu am gasit unde sa ma incadrez. este vorba de un Audi A3, an 2007, cod motor BXE.. Problema este la modulul de confort pe stanga spate si anume, nu merge inchiderea centralizata si nici geamul electric pe portiera respectiva. Am facut test si mi-a dat urmatoarele


Thursday,04,December,2014,02:06:52:13314
VCDS Version: Release 908.0
Data version: 20090911



--------------------------------------------------------------------------------
--------------------------------------------------------------------------------


                Address 09: Cent. Elect.       Labels: 8P0-907-279-30-H.lbl
Control Module Part Number: 8P0 907 279 K    HW: 8P0 907 279 K
  Component and/or Version: Bordnetz-SG     H54 2501
           Software Coding: 01880F01901410004F1600001600000000085E175C010000000000000000
            Work Shop Code: WSC 06435 000 08192
           Additional Info: 8P1955119E  Wischer AU350   H01 0130
Fault Codes have been Erased

1 Fault Found:
01333 - Door Control Module; Rear Left (J388)
            004 - No Signal/Communication
             Freeze Frame:
                    Fault Status: 01100100
                    Fault Priority: 2
                    Fault Frequency: 1
                    Reset counter: 116
                    Mileage: 180371 km
                    Time Indication: 0
                    Date: 2014.12.03
                    Time: 14:04:00

             Freeze Frame:
                        ON
                    Voltage: 11.95 V
                        ON
                        ON
                        OFF
                        OFF
                        OFF
A mai intalnit cineva problema asta?

Precizez ca modulul e bun pt ca am inversat modulele de spate intre ele si modulul din stg, merge pe dreapta.

Share this post


Link to post
Share on other sites
MRC

Verifica firele din mansonul de la usa, e posibil sa se fi sectionat.

Share this post


Link to post
Share on other sites
aurelian_bln

Rezolvat. era un fir rupt in burduful de la sofer. MRC , crede-ma ca am verificat burduful de prima data. am verificat si modulul confort principal, cel din portbagaj, si centrala electrica... Pana nu m-am dus pe fir nu am observat ca duce la usa soferului.

Edited by aurelian_bln

Share this post


Link to post
Share on other sites
andrei_221

ce ghinion sa se rupa tocmai firul de LIN.

Share this post


Link to post
Share on other sites
Al Bundy

Am mai gasit asa, oricare fir se poate rupe.

Share this post


Link to post
Share on other sites
F l o r i n

 Problema este la modulul de confort pe stanga spate si anume, nu merge inchiderea centralizata si nici geamul electric pe portiera respectiva. Am facut test si mi-a dat urmatoarele



Aurel - calculator de usa stanga spate.... nu modul confort.  Modulul confort este unul singur.

Share this post


Link to post
Share on other sites
aurelian_bln

Da Florin mi-am dat seama ca am gresit, dar la cat de obosit eram ieri, am scris confort in loc de calculator. Incepuse sa ma doara si capul, mai ales ca schema de pe autodata nu corespundea cu ce era pe masina... Nici culori si nici asezare pini.

Share this post


Link to post
Share on other sites
F l o r i n

se mai intampla... mai exista ele greseli/diferente in Elsa... dar in Autodata....

Share this post


Link to post
Share on other sites
Cr1sti

adaug si eu aici o problema asemanatoare. acum o zi am fost sa spal masina (nu de nebunie, era plina de sare si clorura pe care le dau pe DN), dupa ce am plecat de la spalatorie am observat ca nu mai am confirmarea din avarii in momentul inchiderii/deschiderii usilor din telecomanda. am verificat si pe display imi afiseaza care usa este deschisa sau inchisa. toate functiile usilor merg, lumini, geamuri, se incuie si se descuie fizic din buton sau telecomanda. muzica/boxele merg in toate usile. insa in continuare am o eroare pe door control module de la usile spate dreapta+stanga.



am dat jos fetele de usi pe spate si totul e uscat pe acea parte, nu am condens, totul curat. nu am verificat firele din stalp catre usi, insa mi-e greu sa cred ca au patit ceva amandoua in acelasi timp.



ma gandesc ca pe partea cealalta a armaturii pe unde intra firele din stalp sa nu fie multa apa/condens si astfel sa rezulte eroarea. iar cu vremea asta nicio sansa sa se usuce prea curand. am sters eroarea cu VCDS insa ea reapare.



ce altceva as mai putea face?



ATASEZ SI AUTOSCAN - MULTUMESC!



Thursday,04,December,2014,00:11:28:46862
VCDS Version: Release 10.6.0
Data version: 20100630



--------------------------------------------------------------------------------
--------------------------------------------------------------------------------


Chassis Type: 1K0
Scan: 01 02 03 08 09 10 15 16 17 19 22 25 37 42 44 46 52 55 56 62
          72

VIN: WAUZZZ8P59A005525   Mileage: 87650km/54463miles

01-Engine -- Status: OK 0000
02-Auto Trans -- Status: OK 0000
03-ABS Brakes -- Status: OK 0000
04-Steering Angle -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
22-AWD -- Status: OK 0000
25-Immobilizer -- Status: OK 0000
37-Navigation -- Status: OK 0000
42-Door Elect, Driver -- Status: OK 0000
44-Steering Assist -- Status: Malfunction 0010
46-Central Conv. -- Status: Malfunction 0010
52-Door Elect, Pass. -- Status: OK 0000
55-Xenon Range -- Status: OK 0000
56-Radio -- Status: OK 0000
62-Door, Rear Left -- Status: OK 0000
72-Door, Rear Right -- Status: OK 0000

-------------------------------------------------------------------------------
Address 01: Engine (CCZ)       Labels: 06J-907-115-CCZ.clb
   Part No SW: 8P0 907 115 AE    HW: 8P0 907 115 Q
   Component: 2.0l R4/4V TFSI     0020
   Revision: AAH03---    Serial number: AUX7Z0H5FNA096
   Coding: 0103000C1C0F0160
   Shop #: WSC 10217 599 194365
   VCID: 75EAE38A239B20B4

No fault code found.
Readiness: 0010 0101

-------------------------------------------------------------------------------
Address 02: Auto Trans        Labels: 02E-300-0xx.lbl
   Part No SW: 02E 300 011 BQ    HW: 02E 927 770 AJ
   Component: GSG DSG AG6     431 1805
   Revision: 04843012    Serial number: 00000805310498
   Coding: 0000020
   Shop #: WSC 06314 000 00000
   VCID: 5FC6A122B1678AE4

No fault code found.

-------------------------------------------------------------------------------
Address 03: ABS Brakes (-----)       Labels: 1K0-907-379-60EC1F.clb
   Part No SW: 1K0 907 379 AP    HW: 1K0 907 379 AP
   Component: ESP MK60EC1   H45 0107
   Revision: 00H45001
   Coding: 14426012492200FF281006E6921E00413900
   Shop #: WSC 10101 599 194365
   VCID: 8004025EEC59951C

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC        Labels: 8P0-820-043.lbl
   Part No SW: 8P0 820 043 BH    HW: 8P0 820 043 BH
   Component: KlimavollautomatH08 0100
   Revision: 000562      Serial number: 8P0820043BH
   Shop #: WSC 00000 000 00000
   VCID: 73EEDD922DEF3E84

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect.        Labels: 8P0-907-279-30-H.lbl
   Part No SW: 8P0 907 279 N    HW: 8P0 907 279 N
   Component: Bordnetz-SG     H54 2801
   Revision: 00H54000    Serial number: 00000008560632
   Coding: F58E1BA190141380E800000A000000000009BE056406040364A000000000
   Shop #: WSC 06314 123 08192
   VCID: 48945A7E04E9ED5C

   Part No: 8P1 955 119 F
   Component: Wischer AU350   H10 0040
   Coding: 00056595
   Shop #: WSC 06314

   Part No: 8K0 910 557
   Component: REGENLICHTSENSORH04 0003
   Coding: 00150573
   Shop #: WSC 06314

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J791)       Labels: Redir Fail!
   Part No SW: 8P0 919 475 E    HW: 8P0 919 475 B
   Component: PARKHILFE PLA H07 0102
   Revision: 11001001    Serial number: 84530816201831
   Coding: 000105
   Shop #: WSC 06314 000 00000
   VCID: 4084425E2CD9D51C

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags (J234)       Labels: 8P0-959-655-10.clb
   Part No SW: 8P0 959 655 J    HW: 8P0 959 655 J
   Component: Airbag AU1042 H06 0090
   Revision: --------    Serial number: 003000000000
   Coding: 303142383038303031314A55304C38503053
   Shop #: WSC 06314 000 00000
   ASAM Dataset: EV_Airba10AURB4 001001
   ROD: EV_Airba10AURB4.rod
   VCID: 49925F7A1FE31454

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel        Labels: 8P0-953-549-F.lbl
   Part No SW: 8P0 953 549 F    HW: 8P0 953 549 F
   Component: J0527           H36 0070
   Coding: 0012142
   Shop #: WSC 06314 000 00000
   VCID: 4182475A27D3DC14

   Part No: XXXXXXXXXXX
   Component: E0221           H02 0030

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments        Labels: 8P0-920-xxx-17-MY8.clb
   Part No SW: 8P0 920 932 A    HW: 8P0 920 932 A
   Component: KOMBIINSTR. VDO H15 0820
   Revision: D0H15004    Serial number: 2245H004001935
   Coding: 0129128
   Shop #: WSC 00011 888 96745
   VCID: 326018969275778C

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway        Labels: 1K0-907-530.lbl
   Part No SW: 1K0 907 530 Q    HW: 1K0 907 951
   Component: J533__Gateway   H16 0202
   Revision:   H16       Serial number: 2700K08606021B
   Coding: EDA37F064002022102
   Shop #: WSC 06314 000 00000
   VCID: 356A238A631B60B4

No fault code found.

-------------------------------------------------------------------------------
Address 22: AWD        Labels: Redir Fail!
   Part No SW: 0BR 907 554 A    HW: 0BR 907 554 A
   Component: Haldex 4Motion      3016
   Coding: 0000005
   Shop #: WSC 00000 000 00000
   VCID: 438E4D523DCFCE04

No fault code found.

-------------------------------------------------------------------------------
Address 25: Immobilizer        Labels: 1K0-920-xxx-25.lbl
   Part No SW: 8P0 920 932 A    HW: 8P0 920 932 A
   Component: KOMBIINSTR. VDO H15 0820
   Revision: D0H15004    Serial number: AUX7Z0H5FNA096
   Shop #: WSC 00000 000 00000
   VCID: 326018969275778C

No fault code found.

-------------------------------------------------------------------------------
Address 37: Navigation        Labels: 8E0-035-192-RNSE.lbl
   Part No SW: 8P0 035 192 S    HW: 8P0 035 192 S
   Component: RNS-E HIGH EU   H77 0650
   Revision:      04S    Serial number: AUZBZ7H4108212
   Coding: 0209157
   Shop #: WSC 10102 599 69419
   VCID: 3F8641A25127AAE4

No fault code found.

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver        Labels: 8P0-959-801-MIN3.lbl
   Part No SW: 8P0 959 801 K    HW: 8P0 959 801 K
   Component: Tuer-SG         H03 0060
   Coding: 0000220
   Shop #: WSC 06314 000 00000
   VCID: 438E4D523DCFCE04

No fault code found.

-------------------------------------------------------------------------------
Address 44: Steering Assist        Labels: 1Kx-909-14x.lbl
   Part No: 1K1 909 144 M
   Component: EPS_ZFLS Kl.079 H08 1901
   Shop #: WSC 10101 599 194365
   VCID: 356A238A631B60B4

No fault code found.

-------------------------------------------------------------------------------
Address 46: Central Conv.        Labels: 8P0-959-433.lbl
   Part No: 8P0 959 433 L
   Component:    KSG          H11 0080
   Coding: 1880220002403F3F8505480F4177
   Shop #: WSC 06314 123 12345
   VCID: 458A534A33FBF034

   Component:   Sounder No Answer

   Component:       NGS No Answer

   Component:      IRUE n.mounted

2 Faults Found
01333 - Door Control Module; Rear Left (J388)
            004 - No Signal/Communication
01334 - Door Control Module; Rear Right (J389)
            004 - No Signal/Communication

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass.        Labels: 1K0-959-702-MIN3.lbl
   Part No SW: 8P0 959 802 K    HW: 8P0 959 802 K
   Component: Tuer-SG         H03 0060
   Coding: 0000220
   Shop #: WSC 06314 000 00000
   VCID: 448C4E4E38C1C93C

No fault code found.

-------------------------------------------------------------------------------
Address 55: Xenon Range        Labels: 8P0-907-357.lbl
   Part No: 8P0 907 357 J
   Component: Dynamische LWR  H01 0020
   Revision: 00000001    Serial number:
   Coding: 0000013
   Shop #: WSC 06314 000 00000
   VCID: 4182475A27D3DC14

No fault code found.

-------------------------------------------------------------------------------
Address 56: Radio        Labels: 8E0-035-192-RNSE.lbl
   Part No SW: 8P0 035 192 S    HW: 8P0 035 192 S
   Component: RNS-E HIGH EU   H77 0650
   Revision:      04S    Serial number: AUZBZ7H4108212
   Coding: 0209157
   Shop #: WSC 10102 599 69419
   VCID: 3F8641A25127AAE4

No fault code found.

-------------------------------------------------------------------------------
Address 62: Door, Rear Left        Labels: 8P4-959-801.lbl
   Part No SW: 8P4 959 801 E    HW: 8P4 959 801 E
   Component: Tuer-SG         H04 0040
   Coding: 0000216
   Shop #: WSC 06314 000 1012544
   VCID: 4182475A27D3DC14

No fault code found.

-------------------------------------------------------------------------------
Address 72: Door, Rear Right        Labels: 8P4-959-802.lbl
   Part No SW: 8P4 959 802 E    HW: 8P4 959 802 E
   Component: Tuer-SG         H04 0040
   Coding: 0000216
   Shop #: WSC 06314 000 1012544
   VCID: 4280485622D5C70C

No fault code found.

End   ---------------------------------------------------------------------
Edited by Cr1sti

Share this post


Link to post
Share on other sites
F l o r i n

sterge erorile si vezi daca lucreaza.





daca tot asa face, deconecteaza bateria pt cateva minute, sterge erorile si vezi daca tot asa face

Share this post


Link to post
Share on other sites
Cr1sti

multumesc pentru raspunsul rapid! eroarea reapare in cateva secunde, cu toate astea am scos bateria pentru aprox 5 min si am reconectat-o... la fel. sa o las deconectat pentru mai mult timp?



functiile usilor functioneaza toate. lumini, broasca, muzica, geamuri. desi eu o incui ea nu primeste semnal de la usile spate si nu confirma incuierea/descuierea...

Edited by Cr1sti

Share this post


Link to post
Share on other sites
F l o r i n

poti incerca.... totusi a aparut problema asta de comunicatie si din cauza asta nu semnalizeaza.



dezactiveaza semnalizarea la incuiere/descuiere - activeaza iar... si vezi daca isi revine



verifica la incuiere, daca si usile spate intra in safe

Edited by F l o r i n

Share this post


Link to post
Share on other sites
Cr1sti

la ce te referi in safe? daca se incuie? da am verificat de 3 ori si se incuie descuie la fel cu celelalte. nu aud niciun sunet dubios din usi si nici retard nu au la incuiere.

multumesc din suflet pt sfaturi!

Share this post


Link to post
Share on other sites
Cr1sti

am incercat si cu bateria scoasa o ora, am sters eroarea, dar nimic...



am umblat si la activare/dezactivare semnalizari si tot nimic. masina crede ca nu e incuitata desi fizic este, asa ca nici nu confirma cu semnalizarile.



am incercat si cu WD40 pe la incuietori, nici asta nu a schimbat nimic :(

Share this post


Link to post
Share on other sites
Al Bundy

Am mai gasit problema asta tot la un A3 din 2010. Dupa un reset cu VAS-PC si-a revenit.

Share this post


Link to post
Share on other sites
Cr1sti

pot face ceva cu ajutorul VCDS-ului?



multumesc!

Share this post


Link to post
Share on other sites
draghicimalex

salut. am si eu o problema, de fapt mai multe, cand vreau sa pornesc stropitorile pt parbriz, nu pornesc, in schimb porneste stergatorul din luneta/haion cand vreau sa pornesc stropitorile (pt parbriz). am observat ca nu porneste nici instalatia de  climatizare, si nici geamurile nu se ridica singure cand actionez treapta 2 de la butoane. iar luminile de la interior nu functioneaza totdeauna. Presupun ca este de la unitatea de confort, imi poate spune cineva ce pot face? sa o resetez sau sa modific ceva valori?
Multumesc anticipat.

Share this post


Link to post
Share on other sites
F l o r i n

Ne trebuie mai multe informatii.



1. ce an este masina ?... si ce masina ? in profil vad ca ai un Touran.... si de postat ai postat la Audi A3.

2. asa ai cumparat-o, s-a intamplat deodata, etc...

3. spalatoarele nu au legatura cu geamurile - spalatoarele sunt pe centrala electrica, geamurile pe modulul confort.

4. fa o scanare sa vedem ce erori ai

Edited by F l o r i n

Share this post


Link to post
Share on other sites
draghicimalex

Este un Vw Touran an 2003 1.9 tdi 74 kw 101 cp, a inceput sa faca toate astea de cand am montat un claxon cu compresor (cu releu conectat direct la batrie), dar cand claxonez scade intrensitatea la faruri... dreci cred ca poate s-ar  fi dereglat ceva din cauza asta... sorry ca am postat la A3m doar aici am gasit topic deschis pe tema asta. voi revenii mai tarziu cu diagnoza.

Share this post


Link to post
Share on other sites
draghicimalex

am revenit cu scanarea


Thursday,26,March,2015,10:19:38:62939
VCDS -- Windows Based VAG/VAS Emulator
VCDS Version: Release 12.12.0 (x64)
Data version: 20130910


VIN:    License Plate: GJ10DRX
Mileage: 215519   Repair Order: Cent. Electric Fault Code


                Address 09: Cent. Elect.       Labels: 3C0-937-049-23-M.lbl
Control Module Part Number: 1K0 937 049 F    HW: 1K0 937 049 F*
  Component and/or Version: PQ35 BordnetzSG 1.0 0302
           Software Coding: 00890F000004100000120C000000000000
            Work Shop Code: WSC 00000 000 00000
           Additional Info: 1T0955119C  Wischer VW358  012  0401
                      VCID: 326BFC43ADDABA8E527-8067
7 Faults Found:

02091 - Rear Window Washer Pump (V13)
            006 - Short to Plus
00897 - Windshield Washer Pump (V5)
            006 - Short to Plus
00154 - Windshield Wiper Motor;  Passenger Side (V217)
            004 - No Signal/Communication - Intermittent
01495 - Bulb for High-Beams; Left (M30)
            010 - Open or Short to Plus - Intermittent
00153 - Windshield Wiper Motor;  Driver Side (V216)
            004 - No Signal/Communication - Intermittent
01064 - Terminal 58d; Interior Dimming
            012 - Electrical Fault in Circuit
02399 - Control Circuit for Terminal 30 for Interior Illumination
            006 - Short to Plus - Intermittent



In atasament este scanarea completa (toate erorrile)

Share this post


Link to post
Share on other sites
eugeniusandu

Salut. Problema mea este ca am incercat sa conectez niste scaune cu memorie si dupa ce am conectat alimentarea si incalzirea iar din firele memoriei nu am conectat decat CAN-ul high si low K wire si marsarier restul nu am putut sa le conectez pt. ca nu am oglinzi cu memorie iata ce sumedenie de erori a putut sa-mi dea pe modulul de comfort.                                                                                                                                                                             Friday,17,July,2015,21:01:40:10074
VCDS Version: Beta 11.2.0
Data version: 20110305



--------------------------------------------------------------------------------
--------------------------------------------------------------------------------


Chassis Type: 1J - VW Golf/Bora IV
Scan: 01 02 03 08 15 16 17 19 22 29 35 36 37 39 46 47 55 56 57 75
          76

VIN: WVWZZZ1JZ2B018188   Mileage: 179630km/111616miles
-------------------------------------------------------------------------------
Address 01: Engine        Labels: Redir Fail!
   Part No: 06A 906 032 FK
   Component: 2.0l 2V AGW     G01 3940
   Coding: 00001
   Shop #: WSC 00046
   VCID: 6CD3C083344B
   WVWZZZ1JZ2B018188     VWZ6Z0A3449129

No fault code found.
Readiness: 0110 1101

-------------------------------------------------------------------------------
Address 03: ABS Brakes        Labels: 1C0-907-37x-ESP-F.lbl
   Part No: 1C0 907 379 E
   Component: ESP FRONT MK60      0104
   Coding: 0019458
   Shop #: WSC 00046 615 1234567
   VCID: 2C530083F4CB

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC        Labels: 3Bx-907-044.lbl
   Part No: 3B1 907 044 E
   Component: CLIMATRONIC     V 2.0.0
   Coding: 01000
   Shop #: WSC 01317
   VCID: 2341EBBF9915

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags        Labels: 6Q0-909-605-VW5.lbl
   Part No: 1C0 909 605 A
   Component: 27 AIRBAG VW51 01     01
   Coding: 12855
   Shop #: WSC 00046
   VCID: 224FEEBB860F

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel        Labels: 1J0-907-487-A.lbl
   Part No: 1J0 907 487 B
   Component: Lenkradelektronik   0002
   Coding: 00008
   Shop #: WSC 00000
   VCID: 306B14F3D8E3

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments        Labels: 1J0-920-xx5-17.lbl
   Part No: 1J5 920 946 C
   Component: KOMBI+WEGFAHRSP VDO V13
   Coding: 01112
   Shop #: WSC 00000
   VCID: 316D11F7D3E9
   WVWZZZ1JZ2B018188     VWZ6Z0A3449129

3 Faults Found:
01336 - Data Bus for Comfort System
            37-10 - Faulty - Intermittent
01336 - Data Bus for Comfort System
            49-10 - No Communications - Intermittent
01330 - Central Control Module for Central Convenience (J393)
            49-10 - No Communications - Intermittent

-------------------------------------------------------------------------------
Address 19: CAN Gateway        Labels: 6N0-909-901-19.lbl
   Part No: 6N0 909 901
   Component: Gateway K<->CAN    0001
   Coding: 00006
   Shop #: WSC 01266
   VCID: F0EB54F39863

7 Faults Found:
01336 - Data Bus for Comfort System
            37-10 - Faulty - Intermittent
01336 - Data Bus for Comfort System
            49-10 - No Communications - Intermittent
01330 - Central Control Module for Central Convenience (J393)
            49-10 - No Communications - Intermittent
01331 - Door Control Module; Driver Side (J386)
            49-10 - No Communications - Intermittent
01332 - Door Control Module; Passenger Side (J387)
            49-10 - No Communications - Intermittent
01333 - Door Control Module; Rear Left (J388)
            49-00 - No Communications
01334 - Door Control Module; Rear Right (J389)
            49-00 - No Communications

-------------------------------------------------------------------------------
Address 46: Central Conv.        Labels: 1C0-959-799.lbl
   Part No: 1C0 959 799
   Component: 1L Komfortgerát HLO 0001
   Coding: 00065
   Shop #: WSC 00046
   VCID: F4E358E3EC7B

   Subsystem 1 - Part No: 1C1959801A
   Component: 1L Tõrsteuer.FS KLO 0003

   Subsystem 2 - Part No: 1C1959802A
   Component: 1L Tõrsteuer.BF KLO 0002

5 Faults Found:
01336 - Data Bus for Comfort System
            37-10 - Faulty - Intermittent
01332 - Door Control Module; Passenger Side (J387)
            49-10 - No Communications - Intermittent
01299 - Diagnostic Interface for Data Bus (J533)
            49-10 - No Communications - Intermittent
00849 - S-contact at Ignition/Starter Switch (D)
            25-10 - Unknown Switch Condition - Intermittent
01030 - Central Locking Key Switch; Driver Side; Lock
            29-10 - Short to Ground - Intermittent

End   ---------------------------------------------------------------------

 Dupa ce am taiat firele conectate la CAN si am scos si mufa maro de memorie din scaun s-au sters tioate erorile la urmatoarea scanare.Dupa ce voi conecta toate cablurile de memorie trebuie adaptate scaunele?Alimentarea si incalzirea functioneaza corect memoria imi da batai de cap sa fie oare ca masina mea e in 2 usi si scaune cu memorie s-au pus doar pe 4 usi si modulul scaunului nu e compatibil cu modulul de comfort?

Share this post


Link to post
Share on other sites
F l o r i n

nu e vb de doua sau patru usi... ci iti creeaza probleme pe partea de comunicatie - pe can. De pe ce masina erau scaunele, ce an era, ce cod avea modulul confort.

Share this post


Link to post
Share on other sites
eugeniusandu

Masina era o Bora din anul 2000 dar mai mult nu stiu ca sunt luate de pe net sacunele si respectivul asa le luase si el de la niste dezmembrari din Franta deci nu pot face rost de codul modulului de comfort. Deci nu se poate face nimic raman doar cu functiile pe care le-am conectat electrice fara memorie si incalzire care functioneaza fara probleme.

Share this post


Link to post
Share on other sites
F l o r i n

da-mi ce coduri ai scrise pe modulul scaunului

Share this post


Link to post
Share on other sites
eugeniusandu

Gata domnu` am facut poza modulului codul este: 3B1 959 760A

post-24466-0-50082300-1437391156_thumb.j

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now
Sign in to follow this

  • Recently Browsing   0 members

    No registered users viewing this page.

×
×
  • Create New...

Important Information

Acest site folosește cookie-uri. Continuarea navigării reprezintă acceptul dvs. pentru această folosință. Pentru mai multe detalii privind gestionarea preferințelor privind cookie-uri, vedeți Politica de utillizare cookie-uri
